Fritsch maalbeker 80 ml zirkoniumoxide P7 Premium Line

Art.Nr.

L10850966000

Maalbeker 80 ml volume. Zirkoniumoxide. Met stalen buitenmantel. Inclusief deksel en dichtring. Voor P7 Premium Line. Mogelijk volume 10 - 30 ml Levering zonder maalkogels

Bekijk alle specificaties

excl. BTW 3.194,-

Catalogusprijs 3 650,-

(Alle prijzen zijn exclusief BTW)

Download de PDF

Specificaties

Specificaties
Merk	Fritsch
Afscheider zuigzijde	Nee
Condenser uitlaat	Nee

Productbeschrijving

Fritsch planetenkogelmolen Pulverisette 7 premium line

Met 2 posities voormaalbekers 80, 45 en 20 ml.
Principe: doordat de maalbeker op een schijf juist omgekeerd draait als om zijn as, rollen de kogels langs de wand en slaan vervolgens door de beker tegen de overliggende wand.
Volledig programmeerbaar, uitgevoerd met touchscreen bediening.
Download productbrochure

Toepassingen

Geschikt voor: het zeer fijn malen van hard tot zacht materiaal, droog of in suspensie.
Pharmaceuticals, mechanisch legeren, metallurgie, keramiek, materiaalonderzoek, geologie en mineralogie, chemie, biologie
Applicatiedatabase

Hoge toerental en veiligheid

Doordat de bekers in de schijf verzonken liggen kan een zeer hoog toerental worden bereikt.
Automatische herkenning van het bekermateriaal.
Starten pas mogelijk als beker op juiste manier vastgeklikkt is.

Technische gegevens

Max. afmeting te malen monster: 10 mm
Max. hoeveelheid monster:2 x 30 ml
Eindfijnheid: ca.< 0,1 µ
Geschikt voor maalbekers van: 20, 45 en 80 ml
Afmeting totaal (lxbxh):370 x 530 x 500 mm
Vermogen:1100 W
Gewicht:44 kg
Download gebruiksaanwijziging

Toebehoren

Grinding bowl 80 ml volume for PULVERISETTE 7 premium line

50.9620.00	agate - SiO₂ - with steel casing
50.9630.00	sintered corundum - 99.7% Al₂O₃ - with steel casing
50.9670.00	silicon nitride - Si₃N₄ - with steel casing
50.9660.00	zirconium oxide - ZrO₂ - with steel casing
50.9610.00	stainless steel - Fe - Cr - Ni - with steel casing
50.9650.00	tempered steel - Fe - Cr - with steel casing
50.9640.00	hardmetal tungsten carbide - WC - with steel casing

Grinding bowl 45 ml volume for PULVERISETTE 7 premium line

50.9720.00	agate - SiO₂ - with steel casing
50.9730.00	sintered corundum - 99.7% Al₂O₃ - with steel casing
50.9770.00	silicon nitride - Si₃N₄ - with steel casing
50.9760.00	zirconium oxide - ZrO₂ - with steel casing
50.9710.00	stainless steel - Fe - Cr - Ni - with steel casing
50.9750.00	tempered chrome steel - Fe - Cr - with steel casing
50.9740.00	hardmetal tungsten carbide - WC - with steel casing

Grinding bowl 20 ml volume for PULVERISETTE 7 premium line

50.9820.00	agate - SiO₂ - with steel casing
50.9830.00	sintered corundum - 99.7% Al₂O₃ - with steel casing
50.9870.00	silicon nitride - Si₃N₄ - with steel casing
50.9860.00	zirconium oxide - ZrO₂ - with steel casing
50.9810.00	stainless steel - Fe - Cr - Ni - with steel casing
50.9850.00	tempered steel - Fe - Cr - with steel casing
50.9840.00	hardmetal tungsten carbide - WC - with steel casing

Further accessories (also suitable for gassing lids premium line )

84.0342.15	replacement seal ring Silicone for all grinding bowls premium line 80 ml, 45 ml, 20 ml volume
84.0341.15	replacement seal ring Viton for all grinding bowls premium line 80 ml, 45 ml, 20 ml volume
50.9900.00	special emptying device for all grinding bowls premium line 80 ml, 45 ml, 20 ml volume
50.9890.00	counterweight for all grinding bowls premium line 80 ml, 45 ml, 20 ml volume

Grinding balls 20 mm diameter for grinding bowl 500 ml, 250 ml, 80 ml

55.0200.05	agate - SiO₂ - polished
55.0200.06	sintered corundum - 99.7% Al₂O₃
55.0200.31	silicon nitride - Si₃N₄
55.0200.27	zirconium oxide - ZrO₂
55.0200.10	stainless steel - Fe - Cr
55.0200.09	tempered steel - Fe - Cr
55.0200.08	hardmetal tungsten carbide - WC

Grinding balls 15 mm diameter for grinding bowl 500 ml, 250 ml, 80 ml, 45 ml

55.0150.05	agate - SiO₂ - polished
55.0150.06	sintered corundum - 99.7% Al₂O₃
55.0150.31	silicon nitride - Si₃N₄
55.0150.27	zirconium oxide - ZrO₂
55.0150.10	stainless steel - Fe - Cr
55.0150.09	tempered steel - Fe - Cr
55.0150.08	hardmetal tungsten carbide - WC

Grinding balls 10 mm diameter for grinding bowl 500 ml, 250 ml, 80 ml, 45 ml, 20 ml, 12 ml

55.0100.05	agate - SiO₂ - polished
55.0100.06	sintered corundum - 99.7% Al₂O₃
55.0100.31	silicon nitride - Si₃N₄
55.0100.27	zirconium oxide - ZrO₂
55.0100.10	stainless steel - Fe - Cr
55.0100.09	tempered steel - Fe - Cr
55.0100.08	hardmetal tungsten carbide - WC

Grinding balls 5 mm diameter for grinding bowl 500 ml, 250 ml, 80 ml, 45 ml, 20 ml, 12 ml

55.0050.05	agate - SiO₂ 5 mm dia., polished
55.0050.27	zirconium oxide - ZrO₂
55.0050.10	stainless steel - Fe - Cr
55.0050.09	tempered steel - Fe - Cr
55.0050.08	hardmetal tungsten carbide - WC

Grinding balls ≤ 3 mm diameter for grinding bowl 500 ml, 250 ml, 80 ml, 45 ml, 20 ml, 12 ml (100 g package)

55.0030.27	3 mm dia. zirconium oxide ZrO₂
55.0020.27	2 mm dia. zirconium oxide ZrO₂
55.0015.27	1.5 mm dia. zirconium oxide ZrO₂
55.0010.27	1 mm dia. zirconium oxide ZrO₂
55.0005.27	0.5 mm dia. zirconium oxide ZrO₂
55.0001.27	0.1 mm dia. zirconium oxide ZrO₂
55.0030.10	3 mm dia. stainless steel - Fe - Cr - Ni
55.0010.10	1 mm dia. stainless steel - Fe -Cr - Ni
55.0030.09	3 mm dia. tempered steel - Fe - Cr
55.0010.09	1 mm dia. tempered steel - Fe - Cr
55.0030.08	3 mm dia. hardmetal tungsten carbide - WC
55.0016.08	1.6 mm dia. hardmetal tungsten carbide - WC
55.0006.08	0.6 mm dia. hardmetal tungsten carbide - WC

Accessories for grinding under inert gas and for mechanical alloying

Gassing lid with valves and seal for all premium line grinding bowls

50.9627.00	agate SiO₂ - with steel casing
50.9637.00	sintered corundum - 99.7% Al₂O₃ - with steel casing
50.9677.00	silicon nitride - Si₃N₄ - with steel casing
50.9667.00	zirconium oxide - ZrO₂ - with steel casing
50.9617.00	stainless steel - Fe - Cr - Ni - with steel casing
50.9657.00	tempered steel - Fe - Cr - with steel casing
50.9647.00	hardmetal tungsten carbide - WC - with steel casing

EASY GTM - Gas pressure and temperature measuring system for controlling the milling process

81.0013.00	receiver unit - board for inserting in the Planetary Mill premium line
50.9050.00	80 ml grinding bowl made of tempered steel with special lid and transmitter
50.9060.00	80 ml grinding bowl made of hardmetal tungsten carbide with special lid and transmitter
50.9070.00	80 ml grinding bowl made of zirconium oxide with special lid and transmitter

Grinding set selection aid for the PULVERISETTE 7 premium line

Material data for the grinding bowls/balls

Material	Main component of the material	Density g/cm³	Abrasion resistance	Used for grinding material
Agate	SiO₂	2.65	good	soft to medium-hard samples
Sintered corundum	Al₂O₃ (99.7%)	3.8	fairly good	medium-hard, fibrous samples
Silicon nitride	Si₃N₄	3.25	excellent	abrasive samples, iron-free grinding
Zirconium oxide	ZrO₂	5.9	very good	fibrous, abrasive samples
Stainless steel	Fe – Cr – Ni	7.8	fairly good	medium-hard, brittle samples
Hardened steel	Fe – Cr	7.9	good	hard, brittle samples
Hard metal tungsten carbide	TC	14.3	very good	hard, abrasive samples

I. Grinding balls ≥ 5mm: Recommended number of balls per grinding bowl

Grinding bowl/ Useful capacity (grinding material)	20 ml 1 – 9 ml	45 ml 3 – 20 ml	80ml 10 - 30ml
Balls diameter
20 mm			5
15 mm		7	10
10 mm	10	18	25
5 mm	80	180	250

II. Grinding balls ≤ 3 mm: Recommended ball mass per grinding bowl in grams

Grinding bowl/ Useful capacity (grinding material)	20 ml 1 – 9 ml	45 ml 3 - 20 ml	80 ml 10 – 30 ml
Material
Zirconium oxide	30 g	70 g	100 g
Stainless steel / tempered steel	40 g	90 g	150 g
Hard metal tungsten carbide	80 g	200 g	300 g
