IKA C1.50 dot matrix printer calorimeter & viscometer

The C 1.50 serial dot matrix printer can be connected to IKA Calorimeter C 6000, C 1 and ROTAVISC,ROTAVISC SBS series rotational viscometers.

In addition to the printing paper roll and cartridge, the package includes two serial cables. The 2 m long serial cable 25 (M) to 9 (F) pin cable, ID# 4453600, can be connected directly to theserial RS 232 9 (M) interface of the above mentioned calorimeters.

The 1.5 m long crossed null modem cable 9 (M) to 9 (M), ID# 25005322, serves as an intermediateconnector and extension to the RS 232 interface of the ROTAVISC or ROTAVISC SBS

Graphical representation of the cable connections:

C 1.50 : 25 (F)------25 (M)------Kabel------9 (F)------9 (M) : Calorimeter

C 1.50 : 25 (F)------25 (M)------Kabel------9 (F) : 9 (M)------Kabel------9 (M)------9 (F) : ROTAVISC
