Thermansys moffeloven 8 liter 1100°C met hefdeur

The Muffle families were designed to provide aflexibleand functional laboratory solution. These Chamber furnaces operate under harsh and demanding thermal processes environment up to 1200 ˚C. Suitable for many applications including Metals Melting, Organics Combustion, Ceramics Sintering, Annealing, Steel Hardening, Ashing and Burn off. Ideal choice for wax removal this model presents an every-day partner for professionals working in dental, jewelry or other similar areas.

• Maximum Continuous Temperature 1200 ˚C.
• Kanthal FeCrAl exposed type resistors.
• Available standard models heated volume from 2.6 to 150 litters.
• Highly resistant in thermal shock.
• Perfect choice for ceramics, jeweler and dental. restoration manufacturers and technicians.

Standard equipped with a Digital LCD display temperature controller providing 15 step programming with 1 program storage.
Optionally equipped with a sophisticated, remote, touch screen, temperature controller, running the specially designed PYROLOGISM 2.0 software, provides a really unique and friendly, windows oriented architecture interface with multiple, advanced features and peripherals.

Key Features

• Control strategy by Thermansys PCC (Power Consistent Control) insures silent operation and compliance with EMC standards.
• Modern double wall construction keeps external surfaces temperature low, emphasizing in operator safety.
• PID control, accurate and uniform temperature profiles.
• KANTHAL® FeCrAl resistors.
• Lift up door keep hot surfaces away from operator.
• ±5 ˚C temperature uniformity.
• Power and true RMS Current measuring circuits.
• Heater failure, open control thermocouple detection alarms and interlocks.
• Stand alone over-temperature limiter (Watchdog) with manual reset in accordance with EN 60519-2 to protect the heater and load. Alarm event output (dry contact 3A/250V AC/DC).

Specifications

• Maximum continuous temperature 1200˚C.
• Operating Power: 208 /240VAC – 50/60Hz.
• Two in depended S type embedded thermocouples for controller and over-temperature limiter feedback (1200C models).
• Two in depended Κ type embedded thermocouples for controller and over-temperature limiter feedback (1100C models).
• Temperature control accuracy ±0.5 ˚C.
• Semi-exposed resistors type.
